ULYS TT-M Modbus
Energy meter for three-phase networks - Connection to CT - Modbus - MID
ULYSFLEXMODBUS
Certification
Communication
Compact product
Easy installation
Product presentation
Thanks to its flexible current sensors with a very wide dynamic range, ULYS FLEX is the ideal solution for feeders with difficult access where the installation of a classic solution on a CT proves difficult and expensive or on high-power feeders.
Intended for energy metering and management applications, ULYS FLEX can be used locally with its 3-line backlit screen or remotely via its integrated communication.
ULYS FLEX Modbus offers the following main features:
- Current inputs on Rogowski coils supplied
- Programmable calibres: 500, 4,000 or 20,000 A without changing the loop and with the possibility of different calibres per phase.
- Measurement capacity up to 140% of calibre
- Voltage measurement inputs: 3 x 10/17 to 285/495 Vac
- Auxiliary power supply: 85 – 265 Vac
- Multi-measurement:
- For 3-wire three-phase, 4-wire three-phase or single-phase networks
- Data available on the screen or or via communication
- On-off output configurable in metering pulse mode or alarm mode
- Phase order error indicator
- Integrated Modbus RS485 communication
- Lead-sealable terminal covers
The integrated RS485 communication provides a direct interface between ULYS FLEX and our Elog datalogger, our supervision system based on the E.ONLINE energy management software and any other third-party system (e.g. PLC, TBM, CTM, etc.)
This meter, supplied with its Rogowski coils, is available in 4 different kits according to the coil size and the cable length.
- ULYS FLEX Modbus Kit 30/10: Loop circumference: 30 cm Cable length: 10 metres
- ULYS FLEX Modbus Kit 70/10: Loop circumference: 70 cm Cable length: 10 metres
Certification
Communication
Compact product
Easy installation
Contact a sales representative
Need information about our solutions? Our experts are available to advise you and assist you with your project. Contact a sales representative now for a detailed presentation and a quote tailored to your needs.
Video
ULYS range energy meters
ULYS meters are the essential tool for a connected and highperformance metering plan.
Highlights
- Simplified mounting for feeders with difficult access
- Wide dynamic range for measurement from 0.3 to 28,000 A
- Multi-measurement: U, V, I, P, Q, S, PF, Tg …..
- Ea, Eq and Es energy index, per phase and total
- Bidirectional metering and measurement on all 4 quadrants
- Compact: 4 DIN on Rogowski coils supplied
- Accuracy: Class 1 from 5 to 100 % of full scale
- Modbus RS 485 communication
Features
Electrical specifications / Auxiliary power supply
Voltage range
85… 265 Vac
Maximum consumption
1,6 VA - 1 W
Frequency
50/60 Hz
Electrical specifications / Voltage measurement
Voltage range
3 x 10/17… 3 x 285/495 Vac - 50/60 Hz
Minimum voltage
20/35 Vac (multiplied by the VT ratio) with direct connection
Electrical specifications / Current measurement
Maximum value
3 selectable calibres (FSA) 500 A (700 A max), 4000 A (5600 A max) or 20 000 A (28 000 A max)
Starting current (Ist)
0.3 A for FSA 500 A, 1 A for FSA 4000 A, 10 A for FSA 20 000 A
Minimum current
70 A for FSA 500 A, 400 A for FSA 4000 A, 1500 A for FSA 20 000 A
Electrical specifications / Accuracy
Voltage
±0.2% reading within the range 10% FS... FS (FS = full scale value)
Current
±0.4 % reading of 5 % FS... FS range
Power
±0.5% reading ±0.1% FS (PF = 1)
Frequency
±0.1 % reading ±1 digit in the 45...65 Hz range
Active energy
Class 1 compliant with IEC/EN 62053-21 (meter + toroid)
Reactive energy
Class 2 compliant with IEC/EN 62053-23 (meter + toroid)
Electrical specifications / Display & keypad
Display
Backlit LCD, 43 x 29 mm - 3 lines, 4 digits + symbols
Keypad
3 keys + 1 protected button
Electrical specifications / Communication port
Type
RS485 optoisolated
Protocols
MODBUS RTU / ASCII
Baud rate
300… 57 600 bps
Electrical specifications / Pulse output
Type
Optoisolated and polarised passive electronic output
Maximum values (compliant with IEC/EN 62053-31)
27 Vdc - 27 mA
Energy pulse length (for DO in Pulse mode)
50±2 ms ON time
Mechanical specifications /
Connection
Measurement terminal block (A & V) 1.5 ... 6 mm². Terminals for digital output, power supply, RS485 port 0.14 ... 2.5 mm².
Ingress protection
IP51 front panel - IP 20 terminal blocks
Format
4 DIN modules
Assembly
On 35 mm DIN rail
Environment /
Temperature of use
-25°C to +55°C
Storage temperature
-25°C to +75°C
Relative humidity
Max 80% non-condensing
Documentation and support
Contact support
Have a question about using or installing your equipment? Our support team is available to provide you with quick and effective solutions. Contact support for personalized assistance.
References and accessories
To fully meet your expectations, a range of accessories is available that is compatible with your equipment. Feel free to add them to your quote request to obtain a complete and tailored solution.
ULYSFLEX energy sub-meter Modbus Rogowski coil 30/10
P01331048
ULYSFLEX DIN rail format energy sub-meter - Modbus communication - 30/10 Rogowski coil
ULYSFLEX energy sub-meter Modbus Rogowski coil 70/10
P01331049
ULYSFLEX DIN rail format energy sub-meter - Modbus communication - 70/10 Rogowski loop
